Description
| POWER SUPPLY | 12..35 Vdc; 8..24 Vac |
| POWER CONSUMPTION @24V | 4 W |
| INSULATION | 4 kV a 3 vie |
| STATUS INDICATORS | Optical fiber communication, serial communication, device status |
| OPERATING TEMP. | -40..+85°C |
| DIMENSIONS (WXHXD) | 71 x 95 x 60 mm |
| WEIGHT | 200 g |
| CUSTODIA | PVC, white |
| MOUNTING | Guida DIN 46277 |
| CONFIGURATION | Software SENECA Compositor (S485-FO-MONO-…); DIP Switch (S485-FO-MULTI-…) |
| BUILT-IN DIAGNOSTICS | Sì |
| STANDARDS | CE |
| NORMS | EN 61000-6-4, EN 61000-6-2 |
| COMMUNICATION PORT | N°1 RS485 optoisolated |
| N° MAX CONVERTERS IN SERIES | 1.000 |
| N° MAX INDEPENDENT NETWORKS | 6 |
| OPTICAL FIBER ANDE CONNECTORS | Single mode, LC connectors (S485-FO-MONO-…); Multidrop (62,5/125 o 50/125 µm), ST/ST connectors (S485-FO-MULTI-…) |
| AREA RANGE | 10 km (S485-FO-MONO-…); 2 km (S485-FO-MULTI-…) |
| INTERFACE AND PROTOCOLS | ModBUS RTU, trasparente ai protocolli di comunicazione |
| DATA RATE | Da 1.200 a 115.200 bps |
